56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — STX4200 9
WARNING: To prevent accidental starting that could
cause serious personal injury, always remove the battery
pack from the machine when assembling parts.
MOUNTING THE GUARD (FIG. B1 & B2)
WARNING: Always wear gloves when mounting or
replacing the guard. Take care of the blade on the guard
and protect your hand from cutting.
WARNING: Never operate the machine without
the guard firmly in place. The guard must always be
on the machine to protect the user! When the guard is
fixed, never attempt to remove or adjust the guard, if
a replacement is needed, it should be performed by a
qualified service technician!
NOTICE: Only the guard with icon can be used
with line trimmer head and must NOT be used with brush
cutter head. Be careful to choose the correct guard when
using the machine.
Loosen and remove the two bolts from the guard, align
the guard mounting holes with the assembly holes and
then lock the guard onto the shaft base with the two
bolts, together with two spring washers.
WARNING: Make sure the guard is fixed according
to Fig. B1 & B2, any reverse fixing will cause great
danger!
MOUNTING AND ADJUSTING THE FRONT HANDLE
1. Stop the motor and remove the battery pack from
the machine, if installed.
2. Loosen the wing nut to separate the adjustable front
handle (Fig. C).
C-1 Front Handle C-3 Wing Nut
C-2 Clamping Block C-4 Quick-release Lever
3. Position the slant of the front handle upward
towards the rear handle. Press the handle onto the
upper shaft (Fig. D1).
4. Insert the clamping block into the handle slot (Fig. D2).
5. Mount the quick-release lever and tighten the wing
nut. (Fig. D3).
6. Pull the quick-release lever up to move/rotate the
front handle to a comfortable operating position (Fig.
D4).
7. Fold the quick-release lever to secure the front
handle in place (Fig. D5).
WARNING: Never operate the machine without the
front handle firmly in place.
MOUNTING SHOULDER STRAP
Depress the strap carabiner to open it and attach it onto
the shoulder strap loop (Fig. E1).
There are two ways to release the strap. Take it off from
your shoulder directly (Fig. E2) or depress the carabiner
and disconnect the shoulder strap from the shoulder strap
loop (Fig. E3).
When wearing the strap, no other wearable should
interfere with the release and removal of the strap.
When an emergency occurs, take it off from your shoulder
immediately, no matter what way the strap is in.
WARNING: For safe and comfortable operation,
when using with a 6.0 Ah or higher Ah battery pack,
be sure to use the BH1000 EGO Backpack Link to
relieve the weight on the user’s arms.
WARNING: Do not use shoulder strap and
BH1000 EGO Backpack Link at the same time. This
will prevent quick emergency release of the machine,
resulting in personal injury.
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
WARNING: Always wear eye protection, along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING: To prevent serious personal injury,
remove the battery pack from the machine before
servicing, cleaning, changing attachments or removing
material from the unit.
APPLICATIONS
The product may be used in rain.
You may use this product for the purposes listed below:
Trimming grass and weeds up against walls, fences,
trees and borders.
