Control panel with 6 buttons

To select the functions of the hood just touch the commands.

Light key ON/OFF

Intensive speed selection key (suction

power) - duration 5 minutes: the hood sets this

power and at the end of the 5 minutes returns

to the previous setting.

High-speed selection key (suction power).

Medium-speed selection key (suction power)

- when flashing it indicates the need to wash or

replace the carbon filter. This signal is normally

deactivated. To activate the alarm, disable the

electronic by pressing the 0 button for 3

seconds.

Next, simultaneously press buttons 1 and 2 for

3 seconds; at first, only button 1 will flash, then

both buttons 1 and 2 will flash to indicate

activation. Repeat the procedure to deactivate

the alarm; at first buttons 1 and 2 will flash and

subsequently only button 1 to indicate

deactivation.

Low-speed selection key (suction power) –

when flashing it indicates the need to wash the

fats filter.

Motor key OFF (stand by) – excludes the

electronics – reset wash/replace filters signals.

MOTOR OFF

Press briefly to switch the motor off.

RESET FILTERS SIGNALS

In functioning mode, after carrying out filter

maintenance, press the key until hearing the

sound signal. The flashing LED 1 (grease filter)

or 2 (carbon filter) stops flashing.

EXCLUDING THE ELECTRONICS

Press the key for 3 seconds. The hood

command electronics will be excluded.

This function can be useful during the product

cleaning operations.

Just repeat the operation to reinsert the

electronics.

If the hood fails to operate correctly, briefly disconnect it from

the mains power supply for almost 5 sec. by pulling out the

plug. Then plug it in again and try once more before

contacting the Technical Assistance Service.

Maintenance

Cleaning

Clean using ONLY a cloth dampened with neutral liquid

detergent. DO NOT CLEAN WITH TOOLS OR

INSTRUMENTS. Do not use abrasive products. DO NOT USE

ALCOHOL!

Grease filter

Fig. 11

Traps cooking grease particles.

The grease filter must be cleaned once a month using non

aggressive detergents, either by hand or in the dishwasher,

which must be set to a low temperature and a short cycle.

When washed in a dishwasher, the grease filter may discolor

slightly, but this does not affect its filtering capacity.

To remove the grease filter, pull the spring release handle.

Charcoal filter (filter version only)

Fig. 12

It absorbs unpleasant odors caused by cooking.

The saturation of the charcoal filter occurs after more or less

prolonged use, depending on the type of cooking and the

regularity of cleaning of the grease filter.

In any case it is necessary to replace the cartridge at least

every four months.

The charcoal filter may NOT be washed or regenerated.

Circular charcoal filter

Apply one on each side as cover to both the shield grids of the

motor impeller, then turn clockwise.

For the disassembly, turn counter-clockwise.

Replacing lamps

Fig. 10

Disconnect the appliance from the electricity.

Warning! Prior to touching the light bulbs ensure they are

cooled down.

Replace the old light bulb with the one of the same type as

specified in the feature label or near the light lamp on the

hood.

1. Using a flat head screwdriver or equivalent tool, carefully

pry loose the light cover.

2. Replace the damaged LED or halogen lamp, with one

having the same characteristics, as specified in the label

features or near the lamp:

LED lamp:For replacement, contact the technical

service.

Halogen lamp: 12V - 20W max - G4 (take care not to

touch them with your hands)

3. Reinstall the light cover. (it will snap shut).

If the lights do not work, make sure that the lamps are fitted

properly into their housings before you call for technical

assistance.
