Overview

Overview of Remote Control Buttons

Overview

To Temporarily Switch Off:

Press to temporarily switch off TV (the standby indicator

on the TV set lights

up in red). Press again to switch on TV from standby mode.

After 15-30 minutes without a signal and without any button being pressed,

the TV set switches automatically into standby mode.

VCR DVD on/off:

Press this button to switch

your VCR or DVD on or off.

Selecting Input source:

Press this button

repeatedly until the input of the desired source

appears on the TV screen.

Selecting channels:

If Media Selector is switched to TV or VCR, press

this button to select channels.

For double-digit programme numbers, enter the

second digit within 2.5 seconds.

a) If Media Selector is switched to TV:

Press this button to watch the last channel

selected (the last channel watched for at least 5

seconds).

b) If Media Selector is switched to VCR:

To select a double-digit programme on a Sony

VCR, e.g. 23, press -/- - first and then the

buttons 2 and 3.

a) Recording button:

If Media Selector is switched to VCR, press this

button to record programmes.

b) Resetting to factory set levels:

Press, for a minimum of 3 seconds, to return the

picture and sound settings to the factory default

levels. This will also return the set to the install

condition and the “Auto Tuning” menu will

appear on the screen. If this is the case refer to the

section “Switching on the TV set and

automatically Tuning” (step 4) of this manual.

Freezing the picture:

Press this button to

freeze the picture. Press again to return to the

normal picture.

Selecting Screen format:

Press this button

repeteadly to change the format of the screen (for

more details, please refer to the section “Changing

the Screen format”) of this manual.

Displaying Multi PIP (Picture In Picture):

Press to display Multi PIP mode. Press again to

cancel. For more details, please refer to the section

“UsingMulti PIP (Picture In Picture)”.

a) Selecting channels:

Press this button to

select the number of the next or previous

broadcast channel.

b) Teletext:

These buttons are also used for

teletext operation. For more detail please refer to

the section “Teletext” of this manual.

Displaying the menu system:

Press this

button to display the menu on the screen. Press

again to remove the menu display from the screen.

Selecting Picture mode:

Press this button

repeatedly to change the picture mode.

Muting the Sound:

Press to mute TV sound.

Press again to restore the sound.

Selecting TV mode:

Press to switch off PAP,

Multi PIP, Teletext or video input.

Displaying the time:

Press to switch the time

display on or off (available only when teletext is

broadcast).

Displaying On Screen Information:

Press

to display all on-screen indications. Press again to

cancel.

Media Selector:

With this remote control you can operate not

only this TV but also the main functions of

your VCR or DVD.

Switch on the device you want to operate and next

press this button repeatedly to select the VCR, TV

or DVD. A green light will be momentarily lit to

indicate the chosen function.

Before the first time you want to control

a DVD or VCR by using this remote

control, you have to set it up depending on the

brand of the device to be used. For more details,

refer to chapter “Remote Control Configuration

for VCR or DVD” on page 33.

a) PAP (Picture And Picture):

For more details, please refer to the section

“Using PAP (Picture And Picture)”.

b) Teletext:

Buttons with green symbols are also used for

teletext operation. For more details, please

refer to the section “Teletext” of this manual.

NexTView:

For more details, please refer to the section

“NexTView” of this manual.

Joystick:

a) If Media Selector is switched to TV:

•When MENU is switched on, use these

buttons to operate the menu system. For

details refer to “Introducing and Using

the Menu System” on page 11.

• When MENU is switched off, press OK to

show an overview of all TV channels. Then

press or to select the channel and

then press button to watch the selected

channel.

b) If Media Selector is switched

to VCR or DVD:

Using these buttons you can control

the main functions of your VCR or DVD.

Fastext:

These buttons are also used for

Fastext operation. For more details please refer

to the “Fastext” chapter in the “Teletext”

section of this manual.

Selecting Sound effect:

Press this button

repeatedly to change the sound effect.

Adjusting TV Volume:

Press

this button to adjust the volume

of the TV.

01GBKF50/42SX200K.fm Page 6 Tuesday, January 7, 2003 12:35 PM
