IV. 

The appliance consists of a body, ange at the bottom side /for

water heaters intended for vertical mounting/ or at the sides /for

water heaters intended for horizontal mounting/, protective plastic

panel safety-return valve.

1. The body consists of a steel reservoir (water tank) and housing

(outer shell) with thermal insulation placed in-between made of

ecologically clean high density polyurethane foam, and two pipes

with thread G ½ ‘’ for cold water supply (marked by a blue ring) and

hot water outlet pipe (marked by a red ring).

The inner tank may be of two types depending on the model:

•

Made of steel protected form corrosion by a special glass-

ceramics coating

•

Made of stainless steel

2. The ange is outtted with: electric heater and thermostat.

The water heaters with glass-ceramics coating are outtted with a

magnesium protector.

The electric heater is used for heating the water in the tank and is

managed by the thermostat, which automatically maintains the set

temperature.

The thermostat has a built in overheating safety device, which

switches of power to the heater when the water temperature

reaches excessive values.

3. The safety-return valve prevents the appliance’s complete

emptying in the event the cold water supply is interrupted. The

valve protects the appliance from pressure increases higher than

the allowed value during heating (! pressure increases upon an

increase of temperature), via release of excess pressure during the

drainage opening.

The safety-return valve cannot protect the appliance in the event of

water mains pressure in excess of the acceptable pressure stated for

the appliance.

V. 

Attention! Improper installation and connection of the appliance may

make it hazardous for the health and life of consumers. It may cause

grievous and permanent consequences, including but not limited to physical

injuries and/or death. Improper installation and connection of the appliance

may also lead to damage to the consumers’ property /damage and/ or

destruction/, or to that of third persons, as a result of, but not limited to

ooding, explosion and/or re. Installation, connection to the main water

and power supply, and putting into operation must be carried out by certied

electricians and technical personnel certied in installation of this category

of appliances, who have obtained their license in the state where the

installation and commissioning of the appliance are carried out, and in

compliance with its local legislation.

Notice: The installation of the unit is at the buyer’s expense.

1. 

We recommend the mounting of the device at close proximity to

locations where hot water is used, in order to reduce heat losses

during transportation. In the event the device is mounted in a

bathroom, the selected location must exclude the possibility of

water spray contact from the showerhead or portable showerhead

attachment.

•

 (g. 1a, table 1) –

The appliance is a󰀩xed to

a wall via the mounting brackets attached to the unit’s body (if the

brackets are not attached to the unit’s body, they must be a󰀩xed in

place via the provided bolts). Two hooks are used for suspending

the appliance (min. Ø 10 mm) set rmly in the wall (not included in

the mounting set). The mounting bracket’s construction designed for

water heaters intended for vertical mounting is universal and allows a

distance between the hooks of 220 to 310 mm (g. 1a).

•

 models (g.1b, 1c) – At horizontal

installation the distances between the carrying hooks are di󰀨erent with the

di󰀨erent capacities and these values are indicated in table 2 - g.1b and table

3 - g. 1c

.

In order to prevent injury to user and third persons in the event of

faults in the system for providing hot water, the appliance must be

mounted in premises outtted with oor hydro insulation and plumbing

drainage. Don’t place objects, which are not waterproof under the appliance

under any circumstances. In the event of mounting the appliance in

premises not outtted with oor hydro insulation, a protective tub with a

plumbing drainage must be placed under the appliance.

Notice: the set does not include a protective tub and the user

must select the same.

2. 

Fig. 4:

Where: 1 - Inlet pipe; 2 - Safety valve; 3 - reducing valve (for water

main pressure > 0,6 MPa); 4 - Stop valve; 5 - Funnel connected to

the sewer network; 6 – Hose; 7 - Drain water tap.

Upon connecting the water heater to the water mains you must

consider the indicative color markings /rings/ a󰀩xed to the pipes:

blue for cold /incoming/ water, red for hot /outgoing/ water.

The mounting of the safety return-valve supplied with the water

heater is obligatory. The safety return-valve must be mounted on

the cold water supply pipe, in observance of the direction arrow

stamped on its body, indicating the incoming water’s direction.

Additional stopcocks must not be mounted between the safety

return-valve and the water heater.

Exception: If the local regulations (norms) require the usage

of another protection valve or mechanism (in accordance with

EN 1487 or EN 1489), then it must be bought additionally. For

mechanisms operating in accordance with EN 1487 the announced

operational pressure must be no more than 0.7 MPa. For other

protection valves, the pressure at which they are calibrated must

be 0.1 MPa lower than the one marked on the appliance’s sign. In

these cases the safety valve which the appliance is supplied with

should not be used.

The presence of other /old/ safety return-valves may lead to a

breakdown of your appliance and they must be removed.

Other type of stopping armature is not allowed between the protection

return valve (the protective device) and the appliance.

The attaching of the safety return-valve to threads longer than 10 mm is not

allowed, otherwise this may damage the valve and poses danger for your

appliance.

With appliances for vertical assembly, the safety valve has to be

connected to the ingoing pipe with the safety plastic panel of the

appliance being taken o.

The safety valve and the pipe between the valve and the water heater

must be protected from freezing. During hose draining - its free end must

be always open to the atmosphere (not to be immersed). Make sure that the hose

is also protected from freezing.

Opening the cold-water stopcock of the water supply piping network

and opening the hot-water stopcock of the water-mixing faucet

carries out the lling of the water heater with water. After the lling is

complete, a constant stream of water must begin to ow from the

water-mixing faucet. Now you can close the hot water stopcock.

In the event you must empty the water heater, rst you must cut o󰀨

its power supply. The inow of water from the water mains must rst

be terminated and the hot water tap of the mixing-faucet must be

opened. The water tap 7 (g 4) must be opened to drain the water

from water tank. If there is no such tap build in the pipe line, than

the water can be drain directly from inlet pipe of water tank after

when you disconnect it from water main

In the event of removing the ange, the discharge of several liters of

water, which remain in the water tank, is normal.

Measures must be undertaken to prevent damage from discharging

water during draining

In case that the pressure in the water mains is over the value

pointed out in the above paragraph I, then it is necessary to

assemble a pressure reduce valve, otherwise the water heater

would not function properly. The Manufacturer does not assume any

liability for problems arising out of the appliance’s improper use.

3. 

Make sure the appliance is full of water prior to switching on the

electrical mains power.

3.1. Models with power cord with a plug are connected by

inserting the plug into a contact. They are switched o󰀨 the power

supply by drawing the plug out of the contact.

The wall-plug must be properly connected to a separate electrical

circle that is provided with a protector. It must be earthed.

3.2. The appliance has to be connected to a separate electricity

circuit of the stationary electrical wiring. The connecting has

to be constant- with no plug contacts. The circuit has to be

supplied with a safety fuse (16A) and with inbuilt device to ensure

disconnection of all pole pieces in the conditions of over-voltage

from category III.

The connecting of the conductors of the supply cord of the

appliance has to be carried out as follows:

•

conductor with brown insulation – to the phase conductor of the

electrical wiring (L)

•

conductor with blue insulation- to the neutral conductor of the

wiring (N)

•

conductor with yellow-green insulation – to the safety conductor

of the wiring ( )

3.3. Models without power cord

The appliance has to be connected to a separate electricity circuit

of the stationary electrical wiring. The circuit has to be supplied with

a safety fuse 16A (20A for power > 3700W). Copper single core
