Quick GuideEN

Please scan the QR code on your product in order to have more detailed information.

TROUBLESHOOTING

®/TM/ © 2024 Whirlpool, Produced under license

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does not

ll the water. Display shows:

and F6, both On/O and

START/Pause LEDs are blink-

ing rapidly.

No water in the water supply or the tap is closed.

Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the

dishwasher and reboot.

The sieve in the water inlet hose is clogged; it is

necessary to clean it.

After having carried out the verication and cleaning, turn o and

turn on the dishwasher and restart a new program.

Dishwasher nishes the cycle

prematurely.

Display shows: F15 and both

On/O and START/Pause LEDs

are blinking rapidly.

Drain hose positioned too low or siphoning

into home sewage system.

Check if end of drain hose is placed at correct height (see INSTAL-

LATION).Check for siphoning into home sewage system, install air

admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

Detergent leaks.

Depends on the liquid detergent used and can be

emphasized in case of Delay option is activated.

Small leaks will not cause machine malfunction and can be avoided

by changing liquid detergent type or using tablets.

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.whirlpool.eu/docs and parts-selfservice.europeanappliances.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet).

When contacting our After-sales Service, please state the codes provided on your product’s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label.

The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

:

KEYLOCK - A long press (for 3 seconds) of MULTIZONE button, will

activate the KEYLOCK function. To deactivate the KEYLOCK, long press again.

DELAY -The start of the program may be delayed for a period of time

between 0:30 and 24 hours

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

MULTIZONE - If there are not many dishes to be washed, a half load-

ing may be used in order to save water, electricity and detergent.

Bydefault the appliance washes dishes in all racks.

Please scan the QR code on your product in order to have more detailed information.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

NaturalDry it is a convection drying system which automatically opens

the door during/after the drying phase to ensure exceptional drying per-

formance every day. The door opens at a temperature that is safe to your

kitchen furniture.

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

A

A

B

C

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)

please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may be

removed by pulling it up-

wards.

CUTLERY RACK

(loading example for the cutlery rack)

The third rack was designed to house the cutlery.

UPPER RACK

(loading example for the upper rack)

Load delicate and light dishes: glasses,

cups, saucers, low salad bowls.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

LOWER RACK

For pots, lids, plates,

salad bowls, cutlery

etc. Large plates and

lids should ideally be

placed at the sides

to avoid interferen-

ces with the spray

arm.

(loading example for the

lower rack)

SANI RINSE - This option can be used to sanitize washed dishes. It will

increase nal rinse temperature and add antibacterial wash to the se-

lected program. WARNING: the crockery and plates could be extremely

hot at the end of the cycle.
