English Instruction for use CHEST FREEZERS

fiCONS91214

3

GB

Directions for use

In the following, you will find all the important information

for the use of your appliance.

The instructions for use apply to several models, which is

why details of the information may differ according to the

type of the appliance.

1 Installation (Choice of position for installation)

Strictly avoid high ambient temperatures and direct

sunlight. We advise you to place your appliance in a cool,

well aired, dry room. Installation in the immediate vicinity of

a heat source (heating, oven etc.) is highly inappropriate

(increased compressor performance would be necessary

and, as a result, energy consumption would be considerably

higher).

If the installation near a heat source cannot be avoided, a

suitable insulation plate must be fitted between the

appliance and the heat source (do not use asbestos), or

the following minimum distances must be observed:

x from gas or electric cooker 3 cm

x from radiator or oven 5 cm

x from a wall, piece of furniture or

another appliance 2 cm

Never obstruct the ventilation grid

Larger chest freezers are equipped with a ventilation grille

(k) located below on one side. These appliances can be

placed directly against a wall or a piece of furniture but not

with the side protected with the ventilation grille.

Freezers without ventilation grid

Leave sufficient space between the rear of the appliance

and the wall to ensure that outward flow of warm air is able

to escape.

The appliance must be placed horizontally and on a

levelled base. Only this way can an impeded circuit of the

refrigerant and optimum function be ensured.

IMPORTANT!

Leave the appliance stand in the final position for at

least 2 hours before switching it on, so that the

refrigerant circuit stabilises and no operating problems

occur.

The odour which is typical of all new appliances is easy to

remove.

Thoroughly clean the interior compartment with a mixture of

lukewarm water and vinegar.

Do not use washing liquids, sharp or granular cleaning

implements, or any cleaning products containing soda.

Before connecting the appliance, make sure that the inner

area – especially the corners – is absolutely dry.

Danger warning

Depending on its composition, the refrigerant is easily

inflammable. The refrigerant circuit is hermetically sealed

and the density has been subject to repeated tests.

An improper intervention can cause acute fire hazard.

Omit any mechanical influence on the cooling system,

especially on the condenser as far as available.

With some appliances the condenser is built into the

external wall.

Interventions on the cooling system must be carried out by

professional and authorised personnel only.

IMPORTANT!

Escaping refrigerant can injure your eyes.

In the event of eye contact with the refrigerant, wash your

eyes instantly under plenty of running water and

call/consult an eye specialist immediately.

KLIMATE CLASSES

The appliance, according to its climate category, is meant

for use at certain room temperatures.

These temperatures should not be exceeded! The climate

category for your particular appliance is marked on the

rating plate. The categories are:

name of climate

category

suitable

room temperatures

SN

ST

T

+ 10° C to + 32°C

+ 16° C to + 32°C

+ 18° C to + 38° C

+ 18° C to + 43° C

2 Rating plate

The rating plate (with technical data) is located on the

housing (D) at the rear of the appliance.

Take a note of the technical data

Copy the technical data from the rating plate to here so that

it is at any time readily available, without having to move

the appliance

Model/Type …………….…………………………

Gross capacity ……………………………….litres

Net capacity ………………….……………litres

Operating voltage ………………….……...…...V-50Hz

Maximum absorbed power(W)..……………….Watt

Safety (A) ……………….....………………......Amp

Energy consumption…………………………....kWh/24h

Freezing capacity …………………………….....kg/24h

3 Connection to power supply

Your appliance must be connected to a power socked with

grounded connection, which is conform to the respective

standards and has been installed by an authorised

specialist.

Before you connect the plug of the appliance with the

power socket, make absolutely sure that

the voltage (V) on the appliance’s data-plate corresponds

with that of your mains.

If the voltage differs, notify the after-sales-service or your

dealer immediately, and do not on any account connect the

appliance to the mains.

4 Switching on / off temperature selection

(Thermostat) (l)

The temperature control switches the appliance on and off

and controls/sets the cooling temperature.

To prevent temperature being accidentally modified, the

control is intentionally resistant to turning. To vary the

setting, we recommend to use a coin or screwdriver.

N
