56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — STX420012
machine cools down and the speed indicator turns green,
then restart the machine.
COMMUNICATION TECHNOLOGY
For information on our full range of connected products
and services, including connection instructions, please
scan the QR Code below or visit
www.egopowerplus.eu/connect.
USING THE LINE TRIMMER
Clear the area to be cut before each use. Remove all
objects, such as rocks, broken glass, nails, wire, or line
that can be thrown or become entangled in the cutting
attachment. Clear the area of children, bystanders,
and pets. At a minimum, keep all children, bystanders
and pets at least 15m away; there still may be risk to
bystanders from thrown objects. Bystanders should
be encouraged to wear eye protection. If you are
approached, stop the motor and cutting attachment
immediately.
Before each use, check for damage/worn parts
Check the bump head, guard, shoulder strap, shoulder
strap loop, and front handle and replace the parts that
are cracked, warped, bent, or damaged in any away.
The line-cutting blade on the edge of the guard can
dull over time. It is recommended that you periodically
sharpen it with a file or replace it with a new blade.
WARNING: Always wear gloves when mounting or
replacing the guard or when sharpening or replacing the
line-cutting blade. Note the location of the blade on the
guard and protect your hands from injury.
Check for blockage of the trimmer head
◾ To prevent blockage, keep the trimmer head clean.
Remove grass clippings, leaves, dirt and any other
accumulated debris before and after each use.
◾ When blockage happens, stop the line trimmer and
remove the battery, then remove any grass that may
have wrapped itself around the motor shaft or trimmer
head.
After each use, clean the trimmer.
Adjusting cutting line length (Fig. J)
The trimmer head allows the operator to release more
cutting line without stopping the motor. As line becomes
frayed or worn, additional line can be released by lightly
tapping the bump head on the ground while operating
the trimmer.
NOTICE: Line release will become more difficult if the
cutting line becomes too short.
WARNING: Do not remove or alter the line cutting
blade assembly. Excessive line length will cause the
motor to overheat and may result in serious personal
injury.
Line replacement
NOTICE:
Always use the recommended nylon cutting
line with a diameter of 2.4-2.7mm. Using line other than
that specified may cause the line trimmer to overheat or
become damaged.
WARNING: Never use metal-reinforced line, wire,
or rope, etc. These can break off and become dangerous
projectiles.
1. Remove the battery pack from the line trimmer.
2. Cut 5 m long cutting line, insert the line into the
mounting hole inside the eyelet (Fig. K). Push and
pull the line from the other side until equal amounts
of line appear on both sides of the spool.
3. Press, while rotating the lower cover assembly in the
arrow direction, to wind the line onto the spool until
approximately 15 cm of line is showing on each side
(Fig. L).
4. Push the lower cover assembly down while pulling
on the lines to manually advance the line and to
check for proper assembly of the trimmer head.
NOTE: In case the line is pulled into the trimmer head by
accident, open the head and pull the cutting line out from
the spool. Follow the section “Reloading the cutting
line” in this manual to reload the line.
Reloading the cutting line
When the cutting line breaks from the line outlet or the
cutting line is not released when the trimmer head is
tapped, follow the below steps:
1. Press the release tabs on the trimmer head and
remove the lower cover assembly by pulling it
straight out (Fig. M & N).
NOTE: A flat head screw driver may be required to
depress the release tabs.
2. Remove the cutting line from the spool.
3. With one hand holding the trimmer, use another
hand to grasp the lower cover assembly and align
