You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:

• Visiting our website - docs.whirlpool.eu

• Using QR Code

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When

contacting our After-sales Service, please state the codes provided on your product’s identi cation plate.

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.whirlpool.eu/register

EN

Quick guide

Before using the appliance read the Safety Instructions carefully.

xxxxxxxxxxxx

xxxx

Eco Monitor

This indicator shows the energy consumption level according to

the programme and the options set. The consumption is

proportional to the lines on the display, by the ecomonitor icon.

OPENING THE DOOR DURING THE CYCLE

Laundry can be checked while the drying cycle runs and any

garments already dry can be removed, while drying continues for

the remaining items. After closing the door, press the "Start/Pause"

button to resume machine operation.

Keep the door closed until the cycle end to save time and energy.

NAVIGATION

The "UP" and "DOWN" buttons are used to navigate the available

menus.

• Press the button to conrm the selection.

• Press the option button at the symbol, where present on the

display, to return to the previous screen.

If no selection is conrmed, after about 2 minutes, the display

return to the main screen.

SETTINGS

To access the Settings menu, press and hold the relevant button for a

few seconds.

• Set language shows the available languages on the display.

• Sounds allows to enable or disable the sounds (some sounds, as

warnings, will remain active anyway).

• Brightness allows to modify the display brightness.

• Factory Default allows to reset the default settings. After having

selected the setting, press and hold the button for a few

seconds.

FIRST TIME USE

When starting the appliance the rst time, the control panel will

automatically show the set language menu. The UP and DOWN

buttons are used to show the languages available in the

machine. Press the button to conrm. The machine cannot be

used without having selected the language.

Make sure that the water tank is correctly inserted.

The dryer must be installed in a room with a temperature

ranging between 5°C and 35°C to ensure proper operation.

Before using the dryer make sure it has been in an upright

position for at least 6 hours.

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to empty your water tank after each drying cycle.

- remember to clean your lters after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door and load garments; always refer to instructions on

clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door lter. Do not load items that

are dripping wet. Do not tumble dry large, very bulky items.

3. Close the door.

4. Press the "On/O" button.

5. Select the most suitable programme

for the type of fabric in that

load.

6. Select the options, if necessary.

7. Press the "

Start/Pause"

button to begin drying.

8. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Pull the load out

immediately to prevent the formation of creases on laundry.

9. Turn the machine o by pressing the "On/O" button, open the

door and pull the clothing out. If the machine is not switched o

manually, after about a quarter of an hour from the end of the

cycle , the appliance turns o automatically to save energy.

Note that some programme/option accords with "Crease Care"

system. This means that for some hours, after the end of the

drying cycle, the drum rotates at regular intervals to prevent the

formation of creases.

In case of power failure, it is necessary to press the "Start/Pause"

button to restart the cycle.

*MAX LOAD 9 Kg (Dry load)

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the  rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

INDICATORS

Cycle phase: Drying - Cool Down - End of Cycle

Empty water tank - Clean secondary lter - Clogged door lters - Autoclean - Eco Monitor

Refer to Troubleshooting section:

Failure call After-sales Service -

DEMO

Demo Mode

CONTROL PANEL

1 Programme selection knob

2 On/O button

3 Start/Pause button

Options buttons

4 FreshCare+

5 Cycle End Signal

6 Rapid

7 Cycle Options (hold for Settings)

8 Dryness Level

9 Timed Drying

10 Start Delay

Navigation buttons and Key Lock

11 UP

12 DOWN

13 CONFIRM (hold for Key Lock)

1

SYNTHETICS

1:35

-:--

-:--

5

6

7

11

12

13

2

3

4

8 9 10
